CSB Battery HRL1210W User Manual
Hrl 1210w, 12v 10w, Powered by

14.4 to 15.0 VDC/unit Average at 25 (77 )
Cells per unit
Voltage per unit
Capacity
Weight
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
Nominal Operating Temperature Range
Float Charging Voltage
Recommended Maximum Charging
Current Limit
Equalization and Cycle Service
Self Discharge
Terminal
Container Material
6
12
10W @ 15min-rate to 1.67V per cell @25
o
C(77
o
F)
Approx.1.1 kg(2.43 lbs)
40A(5sec)
Approx. 35
m
25
o
C±3
o
C (77
o
F±5
o
F)
1A
CSB Batteries can be stored for more than 6 months at
25
o
C (77
o
F). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
F2-Faston Tab 250
ABS(UL 94-HB) & Flammability resistance of
(UL 94-V0) can be available upon request.
Discharge: -15 ~50 ( 5 ~122 )
Charge: -15 ~40 ( 5 ~104 )
Storage: -15 ~40 ( 5 ~104 )
Constant Power Discharge Characteristics Unit:W (25
,77 )
Constant Current Discharge Characteristics Unit:A (25
,77 )
HRL 1210W
12V 10W
Specification
Powered by
HRL 1210W is specially designed for high efficient discharge
application. Its characteristics are high energy density, small
footprint and high discharge efficiency. It can be used for more
than 260 cycles at 100% discharge in cycle service, up to 8
years in standby service.
13.5 to 13.8 VDC/unit Average at 25 (77 )
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length
(L)
70.0±1.0 (2.76±0.04)
64.0±1.0 (2.52±0.04)
178.0±2.0 (7.01±0.08) 34.0±1.0 (1.34±0.04)
F.V/Time
2MIN
4MIN
6MIN
8MIN
10MIN
15MIN
20MIN
30MIN
60MIN
90MIN
1.60V
19.2
13.7
10.5
8.84
7.47
5.51
4.24
3.06
1.66
1.29
1.67V
18.3
13.3
10.2
8.70
7.37
5.43
4.20
3.03
1.64
1.28
1.70V
17.9
13.0
10.1
8.64
7.32
5.39
4.18
3.02
1.63
1.27
1.75V
17.1
12.5
9.85
8.37
7.15
5.27
4.10
2.98
1.62
1.26
1.80V
16.3
11.8
9.50
8.10
6.98
5.14
4.02
2.93
1.60
1.25
1.85V
15.6
11.1
9.15
7.83
6.81
5.02
3.94
2.89
1.59
1.24
F.V/Time
2MIN
4MIN
6MIN
8MIN
10MIN
15MIN
20MIN
30MIN
60MIN
90MIN
1.60V
200
147
113
95.6
81.5
60.9
47.0
34.1
18.7
14.7
1.67V
193
143
110
94.0
80.5
60.0
46.5
34.0
18.6
14.6
1.70V
189
140
108
92.9
79.8
59.3
46.3
33.9
18.5
14.5
1.75V
182
134
106
91.0
78.9
58.5
46.0
33.5
18.4
14.4
1.80V
175
128
103
89.1
77.3
57.2
45.2
33.0
18.2
14.3
1.85V
169
121
100
86.6
75.8
55.8
44.5
32.6
18.1
14.2
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
(http://www.csb-battery.com)
by TUV CERT according to ISO 9001,ISO 14001.
The system of manufacturer was certified
RA1308
Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
