CognitiveTPG Advantage DLX User Manual

Page 10

5. Lower the print head. Do not latch the printhead at this

time.

6. Align the notches on the left side of the ribbon take

up core with the left spindle.

7. Gently pull the right take up spindle and insert the

right side of the ribbon take up core.

REMINDER:

THE TEXT ON THE RIBBON LEADER FACES OUT.

8. Latch the printhead and turn the Power ON to take

up the slack in the ribbon leader.

HELPFUL TIP:

THE ADVANTAGE DLX WILL TAKE UP ANY EXCESS RIBBON UPON LATCHING

THE PRINTHEAD.
