Chapter 4: Programming Commands 79 Revision D 12/09
A799-PG00001D
f = 4 link logo print before cut
Prints a logo after the skip distance of “s” before a logo and “p” past a logo and performs a knife cut (1F 03 16 04 s
p).
Immediately before executing a knife-cut command, if s > 0, execute the following:
• skip (feed paper) “s” dot rows (15 s command)
• stop background merging (1D 9B 1 command). Save previous background merging value, so logo prints in the
clear
• set centered justification (1B 61 1 command), saving the previous justification
• if a logo at index F3h is currently defined, print the logo by sending print downloaded bit image, normal size (1D
2F 0 command), without changing the value of current logo.
• reset justification to previous value (1B 61 [previous value])
• skip (feed paper) “p” dot rows (15 p command) a minimum value of 90h, to ensure knife cut occurs after the logo
• restore background merge suspension (1D 9B [previous value])
Related information
This command is utilized in the TPG LogoEZ ® utility. The utility can be used to pre-configure new printers with a default
colorization setup without requiring any application changes. The default setup was designed to provide a general level of
colorization features that would not affect the printer operation. You can expand beyond the default features of the utility by
modifying the application at the host. However, do not attempt to modify the settings within the utility.
LogoEZ ® utility default settings:
f = 1: s = 1H
a = 30H
f = 2: s = 32H
r = 19H
f = 3: s = 1H
r = 7H
t = 1H
f = 4: s = 30H
a = A0H
Set LogoEZ ® attribute mapping
ASCII US ETX ETB a m s
Hexadecimal 1F 03 17 a m s
Decimal 31 03 23 a m s
Values: a = attribute map selector
a , m, s = 0, 0, 0 turn off attribute mapping (all 3 bytes required)
a = 1 selects first attribute mapping definition (of two available)
a = 2 selects second attribute mapping definition
a = 1 or 2, if m = 0 mapping 1 or 2, respectively, is turned off
