Chapter 4: Programming Commands
100
Revision D 12/09
A799-PG00001D
Values:
First variation: String terminated with NUL character. Length k is not specified in command string; it depends on the bar
code being printed.
m
Bar code
d1...dk
length
0
UPC-A
48–57 (ASCII numerals)
Fixed length: 11, 12
1
UPC-E
48–57
Fixed length: 11, 12
2
JAN13 (EAN)
48–57
Fixed length: 12, 13
3
JAN8 (EAN)
48–57
Fixed length: 7, 8
4
Code 39
48- 57, 65- 90 (ASCII alphabet), 32, 36, 37,
Variable length
43, 45, 46, 47 (ASCII special characters)
d1 = dk = 42 (start/stop code is supplied
by printer if necessary)
5
Interleaved 2 of 5
48–57
Variable length (even number)
6
Codabar
65–68, start code 48–57, 36, 43, 45, 46, 47, 58
Variable length
10
PDF 417
32–255
Variable length, maximum 1000 characters
Second variation: Length n specified at beginning of string. Except as noted, 0 < n < 256.
m
Bar code
d1...dn
length
65 UPC-A
48–57 (ASCII numerals)
Fixed length: 11, 12
66
UPC-E
48–57
Fixed length: 11, 12
67
JAN13 (EAN)
48–57
Fixed length: 12, 13
68
JAN8 (EAN)
48–57
Fixed length: 7, 8
69
CODE39
48–57, 65–90 (ASCII alphabet), 32, 36, 37,
Variable length
43, 45, 46, 47 (ASCII special characters)
d1 = dk = 42 (start/stop code is supplied
by printer if necessary)
70
Interleaved 2 of 5 (ITF)
48–57
Variable length (even number)
71
CODABAR (NW-7)
65–68, start code 48- 57, 36, 43, 45, 46, 47, 58 Variable length
72
Code 93
00–127
Variable length
73
Code 128
0–105 d1 = 103-105 (must be a start code)
Variable length
d2 = 0–102 (data bytes) (Stop code is provided
by the printer)
74
Code 128 auto compress
00–255
Variable length
00–FF
75
PDF 417
0–255
Variable length
00–FF
78
Code EAN 128 auto compress
0–255
Variable length
00–FF
79
PDF 417
0–255
Variable length
00–FF
0 < n < 2800
data length specified via
integer n = nH:nL 1D 6B m nL nH d1 . . . dn
The value of m selects the bar code system as described in the table.
The variable d indicates the character code to be encoded into the specified bar code system. If character code d cannot be
encoded, the printer prints the bar code data processed so far, and the following data is treated as normal data.
Exceptions
Code 93 and PDF 417 are only available in A799 native mode.
