CNB HDF1212 - Manual (Page 58)

58
A-3. Specifications
[Video]
Input Composite 4CH, 1.0Vp- p, 75Ω, NTSC / PAL
Output Main Monitor Composite 1CH BNC, 1.0Vp- p, 75Ω, NTSC / PAL
1 CH VGA
Loopback Output 4CH BNC 1.0Vp- p, 75Ω
[Audio]
Input & Output 1CH Line input / 1CH Line output
Aduio Codec ADPCM
[Recording]
Compression Format H.264 Baseline Profile (MPEG4 Part10)
Compression Rate 4 Step Selectable
Frame Rate Realtime mode CIF : MAX. 120 / 100 fps D1 : Channel 1 select only
(NTSC/PAL) Triplex mode CIF : MAX. 60 / 50 fps Half D1 : Channel 1, 2 select only
Recording Mode Time Continuous / Schedule / Motion / Sensor
Motion Detection Each Channel Area selectable
[Display]
Display Rate Real time display per camera
Multiscreen Display 1 / 4 / Auto Sequence
[Playback]
Playback Mode Normal Playback, Various playback speed (forward and backward)
Search Mode Archived data Search, Date/time, Calendar, Event
[Storage]
Internal HDD Interface Type 1 SATA Internal HDD
Max HDD Capacity Support 1000GB
File System Own File System
[Network]
Remote Access Tool ActiveX Base Web, HDxViewer Access
Dynamic IP support With DDNS Server
Network Interface 10/100 bas-T Ethernet(RJ-45)
[Others]
Sensor Input 4CH (TTL, terminal block NO/NC Programmable)
Alarm Output 2CH (TTL, terminal block)
PTZ Camera Control 1 RS-485
Control Applications Via Front Consol Control, USB Mouse, Remote Controller, TCP/IP
(Network) Backup Clip copy to USB, Quick Time (M4V)
Power 12V DC
Dimensions(WxHxD)mm 351x276x71
