23
Set Alarm Duration time from 10 to 300 seconds using button.
Select event type to be synch with Alarm out. The system has internal Buzzer can be synch with events.
Select event type to activate internal buzzer whenever the system detects events.
3-3. Record
Under Record menu, Record configuration options for Recording, Schedule, and Event can be selected.
3-3-1. MENU > RECORD > Record Setting
In the Record Setting, HDD Overwrite, Audio Record, Real-time Recording, Resolution, and Recording
Speed (ips) and Quality for Time/Event Recording options can be selected.
Only camera channel #1 is recordable under D1 resolution.
Only camera channel #1 and# 2 are recordable under Half D1 resolution.
 HDD Overwrite: Overwrite recorded data and continue recording when HDD is full.
 Audio Record: Select Audio Record option to record audio with video images.
Audio will be recorded but it will not be synched with specific channels.
 Real-time Recording: Selecting Real-time Recording will allow performing full recording/playback
speed of 120ips (100ips); however, the system will record 1ips during Playback.
To record data all the times, even during Playback, DO NOT recommend selecting
Real-time Recording option. Max recording speed will be 60(50) ips but the system
will record during playback by unselecting Real-time Recording option.
Real-time Recording None Real-time Recording
Max. Rec/Playback 120(100)ips 60(50)ips
Rec. during Playback 1 ips 60(50)ips
