41
6-2. Server list indication
It indicates server name, IP address, camera and sensor registered in HDxViewer.
It indicates the status of servers (connection and event) and devices (cameras, sensors and alarms).
6-3. Program shutdown, volume, PTZ control, server connection & disconnection
Program shut down button.
If you click button, authentication window to close HDxViewer will run.
If you click any part on HDxViewer program including 'program shut down' with check on of
button of 'use log on/off' in system setup in HDxViewer setup, authentication window will run.
Connect button.
If you click button, it will try connection to the selected server in the server list.
Disconnect button.
If you click button, it will try disconnection to the selected server in the server list.
Server list management button.
If you click button, server management window will run.
PTZ control button.
If you click button, PTZ control window will run.
6-4. Screen division, full screen and switching
You can enlarge a certain channel in full screen by double-click on that.
