XNET Network Dome Camera User’s Guide
5.5. Sensor & Capture Setup
This is the setup page for sensors and video capture conditions. Captured video can be sent to
user by FTP or E-mail upon configuration.
Figure 5-7. Sensor & Capture Setup
Field/Button
Sub Field
/Button
Description
Sensor 1
Select sensor type. There are two types of sensors which are
Normal Open and Normal Close.
Sensor Setup
Name
Input logical name for the sensor.
It sets the condition of video transmission via FTP or E-mail.
The XNET/XNET-Wireless supports 2 types of conditions which
are mutually independent.
Sensor
Select
Check to enable Sensor initiated capture.
Video Capture
Condition
Motion
Detection
Select
Check to enable motion detection initiated capture.
Captured
Video
Select a way of sending captured video. You can send
captured video through FTP or E-mail, or both.
26 of 44
