XNET Network Dome Camera User’s Guide
5.1.1. Log on from Internet Explorer
The URL of the XNET administrative mode is as followings:
http://[Allocated IP address]/admin.htm
Example: http://172.16.64.133/admin.htm
If you changed the HTTP port from default value you can login by typing in:
http://[XNET/XNET-Wireless IP address]:[HTTP port]/admin.htm
Example: http://172.16.64.133:8080/admin.htm
5.1.2. Log on from “
XNET-NVR
”
Select video channel in the viewing window of “
XNET-NVR
”. Selected video channel will be
highlighted. Click
button on the right side of the display screen.
Figure 5-1. Log on to administrative mode from “XNET-NVR”
5.1.3. Input User Name and Password
After fallowing the method which explained in Section 5.1.1. or 5.1.2, the login screen will open.
Input the User Name and Password in the login screen shown in Figure 5-2.
