MAN-70434-0 R EV AA U LTRA ISC S ERIES S LIM C ELL T RANSDUCER
4.2.2 M OUNTING H ARDWARE AND R ECOMMENDED F ASTENER T ORQUE
UltraSlim 1: Torque:
¼ - 20 x 1-3/8 “(typical)
SAE grade 8
10 lb-ft
M6 - 1.0 x 35 mm L,
Property Class 10.9
8 N-m
Setscrews
10 - 32 (Inch Hub)
M5 - 0.8 (Metric Hub)
24 lb-in
4.7 N-m
UltraSlim 2: Torque:
3/8-16 x 2 (typical)
SAE grade 8
32 lb-ft
M10 - 1.5 x 50 mm L,
Property Class 10.9
45 N-m
Setscrews
¼ - 20 (Inch Hub)
M6 - 1.0 (Metric Hub)
7.5 lb-ft
6 N-m
Mechanisms used for industrial automation can tax even the best threaded fasteners. You can
improve the likelihood that bolts and shafts remain secure by using suitable anaerobic “thread
lockers” during the final assembly.
Trademark Information
Loctite is a registered trademark of Henkel Loctite Corp.
Kidder is a registered trademark of Cleveland Motion Controls
P AGE 25 OF 42
