U LTRA ISC S ERIES S LIM C ELL T RANSDUCER MAN-70434-0 R EV AA
4 I NSTALLATION
4.1 R ECEIVING AND U NPACKING
After receiving the Ultra ISC Slim Cell Transducer you should:
 Carefully unpack and handle the equipment
 Compare the received shipment with the packing list
 Report any damage to the carrier and your CMC representative
 Store equipment that will not be used in a clean, dry location
 Take appropriate precautions to prevent moisture, dust and dirt from accumulating in storage
and installation areas
4.2 B EFORE I NSTALLING THE T RANSDUCER
Before you install the Ultra ISC Slim Cell Transducer you should perform the following steps:
 Review the safety considerations (Section 4.2.1 )
 Assemble the mounting hardware and review the torque fastener information (Section 4.2.2 )
 Reference the mounting dimensions (Section 4.2.3 )
 Determine a mounting location (Section 4.2.4 )
 Determine an appropriate mounting style (Section 4.2.5 )
4.2.1 S AFETY C ONSIDERATIONS
Don’t let safety be an afterthought. Before installing, servicing or calibrating review and follow
applicable policies and procedures to ensure worker safety. Machinery must be in a safe state and
be aware of any additional hazards that can arise when installing and calibrating higher force
transducers.
The following points are important to remember:
 When “dead-weights” are used to produce calibration forces, always wear steel-toed
shoes.
 When manually handling weights, use safe lifting practices to avoid injury.
 Size cordage or straps with an ample safety factor to reduce the chances of failure and
falling weights.
 Consider where the cords and weights will travel should a failure occur.
 Check that all hardware is mounted with appropriate fasteners (thread size and pitch,
fastener grade, length of thread engagement).
P AGE 24 OF 42
