2. CONNECTIONS
Back Panel Features
The back panel of the Express 6530 SHDSL NxNTU
is illustrated in Figure 3.
The SHDSL port uses a RJ-45 connector with the
interchange circuits and pinouts listed in Table 3.
Table 3. SHDSL Pin Connections
e m a N e g n a h c r e t n I n o i t p i r c s e D t u o n i P
C / N n o i t c e n n o C o N 3 , 2 , 1
p i t p i t L S D H S 4
g n i r g n i r L S D H S 5
C / N n o i t c e n n o C o N 8 , 7 , 6
The 120 ohm balanced G.703 port uses a RJ-45
connector with the pinouts defined in Table 4. The
G.703 port supports a 2048 Kbps port using a 120
ohm balanced interface that conforms to ITU-T G.703
Section 9.
G.703 X.21 V.28
CONTROL
90-265VAC 48-65Hz
35-80VDC 250mA V.35 / V.36 SHDSL
CUSTOMER
Nx64K
NETWORK
Figure 3. Express 6530 Back Panel
Table 4. G.703 Pin Connections
n i P n o i t c n u F
1 ) g n i r ( r i a p e v i e c e R
2 ) p i t ( r i a p e v i e c e R
3 d l e i h s e v i e c e R
4 ) g n i r ( r i a p t i m s n a r T
5 ) p i t ( r i a p t i m s n a r T
6 d l e i h s t i m s n a r T
7 C N
8 C N
