Page 7 of 12 2475F - Rev: 2/20/2014 8:33 AM
Red on Setup: set scene speed to off
Green on Fan is on
Red on Fan is off
Light LED
Blinking green Setup: Awaiting X10 address
Blinking red Setup: Awaiting X10 address removal
Green Light is on
Red Light is off
Beeper
Beeper
Single beep Enter setup Mode (or transition to next setup Mode)
Double-beep Setup successful, return to Ready Mode
3 Second beep
Return to Ready Mode (either after setup time-out or user-
initiated set button Tap)
Fast beeps on transition to next fan speed
Advanced Features
Software Only Settings
The following settings are available for programming only via compatible software (i.e. HouseLinc):
• Enable/Disable LEDs
• LED Blink on traffic
• Programming Lock
Using FanLinc as a Phase Bridge
FanLinc automatically bridges the electrical phases in your home (via communications with other dual-
band devices on the “other phase”). This is only important if you have powerline only INSTEON products
in your home. If you are relying on FanLinc to bridge the electrical phases, use the following procedure to
confirm bridging:
1) Tap FanLinc light set button four times quickly
FanLinc will start (beeping) once per second
FanLinc light LED will turn green
2) Check the LED behavior of other dual-band devices
• If the “other” dual-band device is blinking green, it is on the other phase
Device provides a phase bridge to FanLinc
• If the “other” dual-band device is blinking red, it is on the same phase
Device does not provide a phase bridge to FanLinc
Relocate if necessary (and practical)
• If the “other” dual-band device is not blinking
Device not within RF range of FanLinc
