Page 5 of 12 2475F - Rev: 2/20/2014 8:33 AM
i. Optional: test by tapping set button a few times
Light will toggle between green (on) and red (off)
ii. Optional: cover LEDs with black electrical tape to avoid unwanted LED glow at night
which may be visible with some fan cowlings
13) While software is highly recommended to manage this hidden device, if you wish to set up any
scenes in FanLinc using the set buttons, it is critical that you do so now. See “INSTEON scenes”
14) Carefully remount cowling with FanLinc inside (or in electrical box). Use cable tie (included) to secure
FanLinc to fan bracket. Align cable tie with the notch on the FanLinc case ensuring that cable tie and
wires will not interfere with any moving parts.
INSTEON Setup
INSTEON remote control is done using scenes. Scenes allow you to instantly “recall” favorite lighting and
appliance settings at the touch of a button (or in response to central control or even a sensor). Each
scene has at least one controller and at least one responder. Simple scenes can be setup using the
instructions below.
Make Fan an INSTEON Responder
Follow the steps below to add your ceiling fan to an INSTEON scene.
1) Tap FanLinc Fan set button until FanLinc beeper & LED indicate the desired fan speed
FanLinc fan LED will be in the desired state (see table below)
Tap Fan Speed Beeper LED
1
st low Single beep Blinks Green Slow
2
nd
medium Double beep Blinks Green medium
3
rd
high Fast Double beep Blinks Green Fast
4
th
off None red
2) Press & hold the scene controller set button until it beeps
1
Controller LED will start blinking
3) Press & hold FanLinc fan set button until FanLinc double-beeps
FanLinc will (beep)-(beep) and the LED will return to previous state
Controller will (beep)-(beep)
1
and its LED will stop blinking
4) If you wish to add your fan to more scenes, simply repeat these steps
5) Temporarily hang the fan from the mounting ring so the fan can spin safely and without obstruction.
Then while safely clear of the fan blades confirm the scene addition was successful by pressing on /
off on your scene controller
FanLinc fan LED will toggle between green and red
Make Light an INSTEON Responder
Follow the steps below to add your ceiling fan light to an INSTEON scene
1) Press & hold the scene controller button until it beeps
2
Controller LED will blink
2) Tap FanLinc light set button until the ceiling fan light is on
FanLinc light LED will be green
3) Press & hold FanLinc light set button until FanLinc double-beeps
1 Most models
2 If the controller does not have a beeper, wait until its LED begins blinking
