Page 6 of 12 2475F - Rev: 2/20/2014 8:33 AM
FanLinc light LED will flash once & return to green
Controller will (beep)-(beep) and its LED will stop blinking
4) Confirm the scene addition was successful by tapping on / off on your scene controller
Ceiling fan light will toggle between on and off
5) If you wish to adjust the light’s scene on-level and/or ramp rate:
Adjusting on-Level:
a. Using your scene controller, adjust the ceiling fan light brightness to the desired
brightness for your scene
b. Repeat Steps #1 and #3 above
Adjusting Ramp Rate:
a. Using your scene controller, adjust the light brightness to correspond with the Ramp Rate
desired (Brighter = Faster, Dimmer = Slower)
b. Double-tap FanLinc light set button
c. Repeat Steps #1 and #3 above
6) If you wish to add FanLinc light to more scenes, simply repeat these steps
Remove FanLinc from a Scene as a Responder
Software is recommended.
Note: If you choose to remove FanLinc from use, it is important that you remove scene memberships
from all controllers. Otherwise, controllers will retry commands repetitively, creating network delays.
Follow the instructions below for each scene controller that FanLinc is a member of.
If you have both fan and light links, removing one will also remove the other. If you’d like to continue using
the other link, you’ll need to re-create it.
For simplicity sake, the steps below do not cover the removal or re-installation of the ceiling fan.
1) Use pull chain to turn fan motor off
2) Tap controller scene button
3) Press & hold controller set button until it beeps
1
Controller LED will start blinking
4) Press & hold controller set button until it beeps again
1
Controller LED will continue blinking
5) Press & hold fan (or light) set button until it double-beeps
Controller LED will stop blinking
6) Temporarily hang the fan from the mounting ring so the fan can spin safely and without obstruction
i. Move safely clear of the fan blades
7) Test by turning scene on and off from controller
LED and Beeper Behavior
LEDs
Fan LED
Green blink slow Setup: set scene speed to slow
Green blink medium Setup: set scene speed to medium
Green blink fast Setup: set scene speed to fast
1 For devices without beepers hold until its LED begins blinking (this may take 10+ seconds)
