INSTALLATION INSTRUCTIONS
CONTENTS
1) Stage 1:- Civil & Mechanical Section Page
1.1 BASIC HINGE GEOMETRY 3
1.2 BASIC CABLE LAYOUT 4
1.3 LOW VOLTAGE CABLE LAYOUT 5
1.4 ATTACHING BRACKETS 5
1.5 ATTACHING THE REAR BRACKET 6
1.6 ATTACHING THE FRONT BRACKET 7
2) Stage 2:- Wiring & Electrical
2.1 FITING THE CONTROL PANEL IN THE CASING 9
2.2 GAINING ACCESS TO MOTOR 10
2.3 INSTALLING THE MOTOR 11
2.4 ADJUSTING OPEN/STOP LIMIT SWITCH 11
2.5 WIRING THE MOTOR 13
2.6 WIRING THE SAFETY PHOTOCELLS 14
2.7INSERTING THE FREQUENCY CARD 14
2.8 WIRING IN THE TUNED ANTENNA 15
2.9 CODING THE REMOTE CONTROLS 15
2.10 POWERING UP THE CONTROL PANEL 15
3) Stage 3:- Commissioning the Control Panel
3.1 INITIAL WIRING & CONTROL PANEL SETUP 17
3.2 OPENING & CLOSING THE GATE 18
3.3 CONTROL PANEL ADJUSTMENTS 19
3.4 AUTOMATIC CLOSE & SAFETY PHOTOCELLS 20
3.5 PROGRAMMING THE REMOTE CONTROLS TO THE
CONTROL PANEL
21
4) Troubleshooting Guide 23
5) Technical Information
5.1 TECHNICAL SPECIFICATIONS 25
5.2 MOTOR TORQUE SETTINGS 26
5.3 ZA5 CONTROL PANEL DESCRIPTION 27
5.4 ZA5 WIRING DIAGRAM 29
5.5 CONTROL PANEL ADJUSTMENTS 30
5.6 ELECTRICAL CONNECTIONS 31
6) Contact Information
