CAME Ati-S324 Kit User Manual
Page 13
12
MOVE THE GATE TO THE DESIRED OPEN POSITION. LOOSEN THE SCREWS
WHICH HOLD THE MICROSWITCH IN POSITION. SLIDE THE MICROSWITCH
ON THE SUPPORT PLATE UNTIL THE MICROSWITCH IS TRIPPED. THEN
TIGHTEN THE SCREWS TO ANCHOR THE MICROSWITCH IN POSITION.
FIXING SCREW
SCREWNUT
SUPPORT PLATE
MICROSWITCH
MICROSWITCH
Fig 11
WORM-
GEAR
