TROUBLESHOOTING

Error Codes

NOTE: Error codes appear on the In Service display.

Error Code

Error Type

Cause

Reset and Recovery

0

Cam Sense

Error

The valve drive took longer than

6 minutes to advance to the next

regeneration position

Unplug the unit and examine the powerhead. Verify that all cam switches are

connected to the circuit board and functioning properly. Verify that the motor

and drive train components are in good condition and assembled properly.

Check the valve and verify that the piston travels freely. Replace/reassemble

the various components as necessary.

Plug the unit back in and observe its behavior. The unit should cycle to

the next valve position and stop. If the error re-occurs, unplug the unit and

contact technical support.

1

Cycle Step

Error

The control experienced an

unexpected cycle input

Unplug the unit and examine the powerhead. Verify that all cam switches

are connected to the circuit board and functioning properly. Enter Master

Programming mode and verify that the valve type and system type are set

correctly with regard to the unit itself.

Step the unit through a manual regeneration and verify that it functions

correctly. If the error re-occurs unplug the unit and contact technical support.

2

Regen

Failure

The system has not regenerated

for more than 99 days (or 7 days

if the Control Type has been set to

Day-of-Week)

Perform a Manual Regeneration to reset the error code.

If the system is metered, verify that it is measuring flow by running service

water and watching for the flow indicator on the display. If the unit does not

measure flow, verify that the meter cable is connected properly and that the

meter is functioning properly.

Enter a Master Programming Mode and verify that the unit is configured

properly. As appropriate for the valve configuration, check that the correct

system capacity has been selected, that the day override is set properly,

and that meter is identified correctly. If the unit is configured as a Day-of-

Week system, verify that at least one day is set ON. Correct the settings as

necessary.

3

Memory

Error

Control board memory failure

Perform a Master Reset and reconfigure the system via Master Programming

Mode. After reconfiguring the system, step the valve through a manual

regeneration. If the error re-occurs unplug the unit and contact technical

support.

UD

Upper Drive

Sync

Power failure install programming

change

Valve will automatically recover.

Fleck SXT Timer JL10 • 19
