PC6172
17” industrial Core 2 Duo Panel PC
1-3 Safety Precautions
Four Analog Line-level Stereo Inputs for Connection.
High Quality CD Input with Ground Sense. Stereo Line-Level Output
Interface: Line-In, Line-Out, Microphone.
- HARDWARE MONITORING FUNCTION : Monitor Voltage, CPU temperature, & Cooling fan speed.
If CPU Temperature is over setting, the buzzer will send out a warming (only under DOS system).
- IRDA PORT : 5-pin Infrared port, support IrDA v1.0 SIR protocol
- GREEN FUNCTION : Controlled by hardware and software.
- LED INDICATOR : System power Hard Disk access LAN LED indicator
- DMA CONTROLLER : 8237 x 2
- DMA CHANNELS : 7
- INTERRUPT CONTROLLERS : 82C59 x 2
- INTERRUPT LEVELS : 15
- OPERATING TEMPERATURE : 0 to 60°C.
- BOARD DIMENSIONS : 170 mm x 170 mm, 6.69" x 6.69"
- BOARD NET WEIGHT : 810 gram.
Follow the messages below to avoid your systems from damage:
1. Keep your system away from static electricity on all occasions.
2. Prevent electric shock. Don't touch any components of this card when the card is power-on. Always
disconnect power when the system is not in use.
3. Disconnect power when you change any hardware devices. For instance, when you connect a
jumper or install any cards, a surge of power may damage the electronic components or the whole
system.
