PC6172
17” industrial Core 2 Duo Panel PC
CHAPTER 1 INTRODUCTION
1-1 General Description
Thank you for purchasing our PC6152 Intel Core 2 Duo/ Core Solo Main board enhanced with VGA/
Sound/LAN, which is fully PC/ AT compatible. The PC6152 provides faster processing speed, greater
expandability and can handle more tasks than before. This manual is designed to assist you how to
install and set up the system. It contains four chapters. The user can apply this manual for configuration
according to the following chapters:
-Chapter 1 Introduction
This chapter introduces you to the background of this manual, and the specifications for this system.
The final page of this chapter will indicate how to avoid damaging this board.
-Chapter 2 Hardware Configuration
This chapter outlines the component locations and their functions. In the end of this chapter, you will
learn how to set jumper and how to configure this card to meet your own needs.
-Chapter 3 Software Utilities
This chapter contains helpful information for proper installations of the VGA utility, LAN utility, Sound
utility, and Flash BIOS Update. It also describes the Watchdog-timer configuration.
-Chapter 4 Award BIOS Setup
This chapter indicates you how to set up the BIOS configurations.
-Appendix A Expansion Bus
This Appendix introduces you the expansion bus for PCI-E x16 BUS.
-Appendix B Technical Summary
This section gives you the information about the Technical maps.
