PC6172
17” industrial Core 2 Duo Panel PC
1-2 System Specifications
- CPU: Intel® Core 2 Duo/ Core Solo/ Celeron® M Socket 478 onboard for 65nm CPU. (Up to
2.16GHz)
- CHIPSET: Intel® 945GME + ICH7R (FSB: 533/667MHz)
- MEMORY : 2 x 200-pin DDR2 SO-DIMM. Support DDR II 667 SDRAM up to 4GB.
- CACHE : Built-in CPU.
- REAL-TIME CLOCK : 256-byte battery backed CMOS RAM. Hardware implementation to indicate
century rollover.
- BIOS : Phoenix-AwardBIOS™ for plug & play function. 8MB with VGA BIOS. Easy update 512KB
flash EEPROM. Support S/IO Setup.
- KEYBOARD CONNECTOR : Mini DIN connector. Supports for AT/PS2 keyboard.
- MOUSE CONNECTOR : Mini DIN connector. Supports for PS/2 Mouse.
- BUS SUPPORT : 1 PCI-E (x16) Slot (SDVO), CF (only available if no IDE device attached)
- DISPLAY : Built-in Intel 945GME, support for CRT, LVDS, TV-Out. Onboard 15-pin VGA D-SUB
connector, support for resolution on QXGA Monitor.
- IDE INTERFACE : One IDE ports support up to two IDE devices. Supports Ultra DMA 33.
- SERIAL ATA PORT : Two S-ATA connectors from ICH7R.
Warning: SATA ports with 5V on board (pin7). Please don't use normal SATA device.
- USB CONNECTOR : Support up to eight USB 2.0 ports.
- LAN ADAPTER : LAN: Intel® 82573V (10/100/1000 Mbps) Support wake-on-LAN function.
- SERIAL PORT : Two high speed 16550 Compatible UARTs with Send / Receive 16 Byte. FIFOs;
COM1/2:RS-232. MIDI Compatible. Programmable Baud Rate Generator
- SOUND : Realtek ALC655 (AC'97 Codec).
Fully Compliant AC'97 Analog I/O Component
16-Bit Stereo Full-Duplex Codec.
