SAFETY INFORMATION
FAILURE TO COMPLY WITH WARNINGS AND CAUTIONS MAY CAUSE PERSONAL
INJURY AND/OR PROPERTY DAMAGE.
Do not use electric pumps in an explosive
atmosphere. Adhere to all local and
national electrical codes.
Do not use hoses, fittings, or couplers with
pressure ratings below 10,000 psi (700 bar).
Install pressure gauges in the system to
monitor operating pressure.
Titan pumps have an internal relief valve
installed under the pump cover. This relief
valve is factory adjusted and must not be
repaired or adjusted except by qualified
hydraulic technicians.
To prevent damage to pump electric motor,
check specifications. Using incorrect
power source will damage the motor.
To help prevent pump failure, check
hydraulic reservoir fluid level prior to
pump operation. When gauge reads low,
add oil. Always be sure cylinders are fully
retracted before adding fluid to the
reservoir. Use only GB Electrical hydraulic
oil. Use of any other oils or fluids may void
your pump warranty.
■
SPECIFICATIONS
Specification “B” Version “E” Version
Operating 0-10,000 psi (700 bar) maximum
Electrical Power Source
Motor Rating
Flow Rate
Unloading (or Bypass)
Pressure
Operating Oil
Temperature
Reservoir Capacity
Shipping Weight
30 Amp/115 Volt Grounded 15 Amp/230 Volt
single-phase, 50-60 Hz single-phase, 50-60 Hz
1 1 ⁄ 8 HP Universal Motor, 0.84 kW Universal Motor,
25 Amp @10,000 psi (700 Bar) and 12,000 RPM 12.5 Amp @ 10,000 psi (700 Bar) and 12,000 RPM
operates at 60-125 Volts, 82-89 dbA operates at 115-240 Volts, 82-89 dbA
640 in 3 /min (10,51/min) @ 0 psi (0 bar)
60 in 3 /min (1,01/min) @ 10,000 psi (700 bar)
1600 psi
150° F (65.5° C) maximum
for operation below 32° (0° C), change oil to MIL-H-5606 (see page 8 for procedure)
1.3, 2.4, 10.4 gallon (5, 9, 20, 40 liter)
53 lbs to 165 lbs (116,6 kg to 363 kg) depending on valve and reservoir configuration
