Gardner Bender BV208D User Manual

Instruction sheet, Bv208d, Special features

background image

IMPORTANT: RECEIVING INSTRUCTIONS: Visually
inspect all components for shipping damage. If any
shipping damage is found, notify carrier at once.

Shipping damage is NOT covered by warranty. The
carrier is responsible for all repair or replacement costs
resulting from damage in shipment.

Instruction

Sheet

BV208D

IMPORTANT—USER SAFETY AND PROTECTION: In setting up systems to fit your operations, care must be taken
to select the proper components and design to insure appropriate integration with your operations and existing
equipment. All safety measures must taken to avoid the risk of personal injury and property damage from your
application or system.

Gardner Bender CANNOT BE RESPONSIBLE FOR DAMAGE OR INJURY CAUSED BY UNSAFE USE,
MAINTENANCE OR APPLICATION OF ITS PRODUCTS.
Please contact Gardner Bender for guidance when you
are in doubt as to the proper safety precautions to be taken in designing and setting up your particular application.

Special Features

• Heavy Duty 8 ft hose. Optional 15 ft. hose available.

• Complete set of tools for injecting pull line into 1/2" to

6" conduit.

• Four gallon recovery compartment. Expandable to

nine gallons on BV208DA.

• Heavy duty welded steel cart with casters and wheels.

Description

Blo-Vac™ power fishing systems, BV208DA. Each
model is designed for blowing or vacuuming pull line into
electrical conduit. In addition, each Blo-Vac also
operates as a standard shop type wet and dry vacuum
cleaner.

The Blo-Vac unit has three compartments which are
easily separated. The top section contains the power
unit, the center
section(recovery
compartment) collects refuse
and the bottom section (tool
storage) is storage for
accessories (see Fig. 1).
Model BV208D is expandable
to 9 gallons. The BV208D is
constructed from high impact
polypropylene.

Blo-Vac Power finishing
system is capable of injecting
cable pull line into 1/2" to 6"
conduit. Accessories and
materials vary depending on
job requirements. Specifications for length of conduit
runs are guidelines and are not applicable 100% of the
time. (See Technical Specifications on page 4).
Conditions such as debris in conduit and fitting leakage
will reduce the effectiveness of the Blo-Vac system.

Power
Unit

Recovery
Compartment

Tool Storage
Compartment

Fig 1
Blo-Vac Compartments
