Dim. & weights
Fluid Components Intl
Document 06EN003327 Rev. - 17 FlexCOR ä Model CMF Series
Sensor Size L
3
H
5
H
6
H
5
+ H
6
in. (mm) in. (mm) in. (mm) in. (mm)
CMF- B 2.95 (75) 3.23 (82) 12.09 (307) 15.31 (389)
CMF - C 2.44 (62) 2.83 (72) 12.48 (317) 15.31 (389)
CMF- D 2.95 (75) 3.43 (87) 12.91 (328) 16.30 (414)
CMF - E 2.95 (75) 6.81 (173) 13.07 (332) 19.84 (504)
CMF - F 2.95 (75) 8.94 (227) 13.07 (332) 21.97 (558)
3.2 Ex-d Compact
version
3.3 IP 67 Compact
version
Sensor size L
3
H
5
H
6
H
5
+ H
6
mm mm mm mm
CMF - B 2.95 (75) 3.23 (82) 9.69 (246) 12.91 (328)
CMF - C 2.44 (62) 2.83 (72) 10.08 (256) 12.91 (328)
CMF - D 2.95 (75) 3.43 (87) 10.51 (267) 13.90 (353)
CMF - E 2.95 (75) 6.81 (173) 10.67 (271) 17.44 (443)
CMF - F 2.95 (75) 8.94 (227) 10.67 (271) 21.97 (497)
Inches (mm)
Inches (mm)
5.12
(130)
10.04
(255.1)
5.16
(131)
6.10
(155)
