ELRO HIS20USB Security & home automation system USERS MANUAL - Manual (Page 6)

6
1-2. Show device information
Click on any device to access a window (see below)
that contains specific information about the device,
such as Device Name, Device Type, Number, Location
and so forth.
Examples:
When you click , the system will display this
message window.
When you click , the system will display this
message window.
1-3. Executing Funckey
Click the following buttons directly in this window to
execute the corresponding Funckey:
: Execute Funckey 1
: Execute Funckey 2
: Execute Funckey 3
The system will display one of the following windows to
inform the user of the status of Funckey execution,
depending on its success or failure.
i.e.: Funckey executed successfully
i.e.: Funckey execution failed
II. Sync
The PC software is intended as an assistive program
for Home Box setup. Setup is only complete after all
the settings made on your PC have been applied to the
Home Box with the Sync function. If you close the
application during setup, Home Box will not recognize
any configuration you have made with the exception of
“Add Device/Remove Device”. (These two actions take
effect immediately.)
To Sync,
4. Select “Sync” in the Top Menu.
5. Click the button located at
the lower right hand corner of the
screen.
The system will send the updated settings to Home
Box. It is recommended that you perform this operation
whenever it is convenient during the configuration
process to prevent potential data loss should the
application freeze in mid-operation.
The Sync window (see below) will appear whenever
the system is writing data back to Home Box to inform
the user that the system is in the process of
synchronizing.
OK
OK
