6518 / 6519 - 13
I
NSTALLATION
, I
NITIALISATION AND
S
ERVICE
english
Dismantling the module
Unlatch both locking hooks by using a screwdriver on the end dismantling-grooves.
Remove the block part / module sideways.
Other possible uses of the connecting module, - right-hand -
• As a separation module for special applications when building up several pressure levels in a single
block
• Additional supply lines for larger valve blocks
Secure the valves to the base module using 2 M4 screws each.
(Tightening torque max. 1.5 Nm).
Mount the complete valve block onto the wall or the standard rail.
Connect the supply and working lines.
Make the electrical connections to the pilot valves: in doing this, observe the values given on the rating
plate!
NOTE Where necessary, break out the rated break-points of Ports 1, 3 and 5 and
the upper pilot venting.
Installation
Hang the valve block onto the upper groove of the standard rail.
Latch the lower clamp into the standard rail.
Firmly tighten the screws on the clamp.
Dismounting
Loosen the clamping screws (by about 4 revolutions).
Remove the block upwards from the standard rail.
Mounting the valve block
Standard rails
• Standard rail 35 x 15 DIN 50022 (Standard)
• Standard rail 75 x 25 DIN 50023
NOTE When using the 75 x 25 DIN 50023 standard rail, change over the pre-assembled screws
with clamps and springs as necessary.
