10

Valve with flanged connection:

Remove the cover plate.

WARNING!

Danger – escaping medium!
Leaking connections if seals not seated properly, if manifold uneven or if
surface quality of the manifold inadequate.

▶ Make certain the seals included with delivery are properly seated in

the valve.

▶ Ensure that the manifold is even.

▶ Ensure that the surface quality of the manifold is adequate.

Insert the seal into the body.

Screw the valve onto the manifold
(Tightening torque max. 1.5 Nm).

6.3 Electric installation

WARNING!

Risk of injury due to electrical shock!

▶ Before reaching into the system, switch off the power supply and

secure to prevent reactivation!

▶ Observe applicable accident prevention and safety regulations for

electrical equipment!

If the protective conductor contact between the coil and body is
missing, there is danger of electrical shock!

▶ Always connect protective conductor.

Note the voltage and current type as specified on the type label.

Procedure:

Check that the seal is correctly seated.

Connect the protective conductor.

english

11

7

MAINTENANCE, TROUBLESHOOTING

7.1 Safety instructions

WARNING!

Risk of injury from improper maintenance!

▶ Maintenance may be carried out by authorized technicians only and

with the appropriate tools!

Risk of injury from unintentional activation of the system and an

uncontrolled restart!

▶ Secure system from unintentional activation.

▶ Following maintenance, ensure a controlled restart.

7.2 Malfunctions

If malfunctions occur, check:
• the line connectors,
• the operating pressure,
• the power supply and valve control.

If the valve still does not switch, please contact your Bürkert Service.

8

DISASSEMBLY

8.1 Safety instructions

DANGER!

Risk of injury from high pressure in the equipment!

▶ Before loosening the pipes and valves, turn off the pressure and

vent the lines.

Risk of injury due to electrical shock!

▶ Before reaching into the device or the equipment, switch off the

power supply and secure to prevent reactivation.

▶ Observe applicable accident prevention and safety regulations for

electrical equipment.

WARNING!

Risk of injury from improper disassembly!

▶ Disassembly may be carried out by authorized technicians only and

with the appropriate tools!

english

12

8.2 Disassembly

Procedure:

Turn off the pressure and vent the lines.

Switch off the power supply.

Valve with threaded connection:

Hold the device with the appropriate tool on the body and screw off
the pipeline.

Valve with flanged connection:

Loosen the valve from the manifold.

9

SPARE PARTS

CAUTION!

Risk of injury and/or damage by the use of incorrect parts!
Incorrect accessories and unsuitable spare parts may cause injuries and
damage the device and the surrounding area.

▶ Use only original accessories and original spare parts from Bürkert.

10 TRANSPORT, STORAGE, DISPOSAL

NOTE!

Transport damages!
Inadequately protected equipment may be damaged during transport.
• During transportation protect the device against wet and dirt in

shock-resistant packaging.

• Avoid exceeding or dropping below the allowable storage

temperature.

• Protect electrical interfaces of the coil and the pneumatic connec-

tions from damage with protective caps.

Incorrect storage may damage the device.
• Store the device in a dry and dust-free location!
• Storage temperature -40 ... +70 °C.
Damage to the environment caused by device components con-
taminated with media.
• Dispose of the device and packaging in an environmentally friendly

manner.

• Observe applicable regulations on disposal and the environment.

english

Type 0641
