electrical connections
attentIon!
the operating voltage and frequency of the electrical supply must
be the same as quoted on the rating plate of the drive. the volta-
ges and currents must not lie outside the permitted operating
range.
M
1
6
2
4 3
5
P1
Rs
rs = 6.8 kΩ
p1 = 1.0 kΩ / 5.0 kΩ
plug configuration
note
With a pulsed drive and nominal voltage, the pulse duration should
not fall below 100 ms.
pol configuration
pin 1 pin 2
left running
plus minus
right running
minus plus
