NOTE: Any changes made to a slide show in iMonitor Express Viewer cannot be saved. To make
changes for future use you will need to use iMonitor Express – iMonitor Viewer.
Closing Dashboards
At any point you may want to close dashboards that are no longer needed or that were opened to
get additional information. To close a dashboard make sure that that it is currently in the active
view. If you are running a slide show make sure you stop it before preceding to prevent closing the
wrong dashboard. Click the in the lower right corner.
iMonitor Settings
After opening iMonitor Express, select ‘iMonitor settings’
OEE configuration
‘Operating time’ settings
In the upper left area you will find the ‘operating time’ setting area. Here it is possible to define
which states should count as operating time in the OEE calculations.
‘Ideal Cycle time’ settings
In the upper right area you will find the ‘ideal cycle time’ area. Here you can specify the ideal cycle
time for your process points. It is only valid for functions and workstations.
‘Planned production time’ settings
In the lower area you will find the ‘planned production time settings’ outlined in a calendar format.
The time you schedule in this calendar is the base for the OEE calculations ( see OEE overview). If no
time is scheduled, a 24/7 schedule is used as default.
