are the same between the selected gadget and/or gauge will show up. Below is a list of some of the
common properties.
• (Name): Displays the name
• Back Color: Color to be used for the background.
• Border Color: Color to be used for boards if they have been enabled.
• Border Width: Width of the border.
• Border Style: Style of the border.
• Dashboard Link: Ability to link gadgets and/or Gauges to other Dashboards. When you are
viewing the dashboard and the item is clicked the linked Dashboard will be presented.
NOTE: With Dashboard links both the parent and child dashboard must be open to work. If you click
the link associated to a dashboard that is not open nothing will happen.
• Fill Color: Color to Fill the Object.
• Font: Used to specify the font and properties of the font.
• ForeColor: Color of the font to be displayed.
• Horizontal Alignment: aligns either left, cent, or right.
• Location: Location of the gadget/gauge on the design grid.
• Show Border: Enable to Disable the border of a gadget/gauge.
• Size: Size of the gadget/gauge.
• Text: Text that you want displayed on the Dashboard
• Vertical Alignment: aligns top, middle, or bottom.
• Clock Style: Option of Analog or Digital for the Clock gadget.
• Data Source – Data Source Type: Type of the associated data source.
• Data Source – Data Source Name: Name of the Data Source.
Each gauge may have its own specific properties. For more information on these specific properties
please reference the Property Information area shown in red below:
