Functions
3 Functions
3.1 Function description
Locating modules are components for positioning pallets in preparation for
operations such as assembly, machining or testing.
The pallets are stopped by a pneumatically controlled stop device near the
desired position. A proximity switch is used to indicate that a pallet is in the
locating station. A locating cross wedge is activated to one side of the pallet
lifting the pallet against a V-ruler on the opposite side of the pallet. The lo-
cating accuracy is within +/-0,1 mm.
The location module is delivered complete with conveyor beam, guide rails
and guide rail brackets for M12 sensors, for installation into a conveyor line.
The sensor for pallet in locating position is always included but other sen-
sors, supports and RFID readers are optional.
Excluded parts:
• Chain
• Slide rails for chain and guide rails
• Tubes for pneumatic circuit
• Pallets
• Cables (for sensors and RFID r/w head)
The locating station is divided into Pre-stop position and Process position.
Pre-stop position
At the pre-stop position pallets are stopped if the process position is occu-
pied. The RFID-reader at the pre-stop can by identifying the pallets in-
crease the efficiency by letting those with an other destination pass quickly.
Process position
The process position receives one pallet at the time from the pre-stop. If the
pallet should be processed, it is caught by the integrated stop. Once it is
located the process will start.
