Technical specification
Created by EBCCW 00:06
9 8050183
2.2 Ordering information
Use the online configurator to order locating module. In the configuration pro-
cess, sensor types and RFID readers are specified. If the optional support is
chosen the height to top of pallet is also specified.
Question Choices Description code
Support type
Top of pallet (TOP)
Sensors
RFID
Configuration example
Example of configurator string: 128-64x64-1000-S-RF
The choice sensor "Yes" includes sensors and brackets for indicating:
• Pallet in pre-stop position
• Pallet in position
• Locating up/down
The choice sensor "No" includes:
• Sensor brackets for pallet in pre-stop position
• Sensor bracket for pallet in position
The choice RFID "Yes" includes:
• Read/write head (5058152)
• Read/write head bracket (8050112)
None
64x64
88x88 None
64x64
88x88
500-1200 mm 500-1200 mm
Yes/No S/N
Yes/No RF/N
