3 Technical bulletin
Twisted conveyor beams
Twisting a split beam
1 Assemble the split beam. There should be at least 5
beam clips per meter. Leave a “clip-free” distance of
100 mm at each end.
2 Mount the standard beam sections at the ends of the
split beam.
3 Mount connecting strips at the ends of the assem-
bled beam section.
4 Place one end of the beam in a vice and tighten it
5 Holding the connecting strips at the other end, twist
the beam, using a lever, to the desired angle.
The twist degree of the split beam has to be proportional
with the length and type of beam required (XL, XM, X85
or XH). Se tables below for further details.
Conveyor system XL
Twist degree (left
or right)
Cutting length
(mm) Number of clips
required
± 15°
± 20°
± 30°
± 45°
± 60°
± 90° 700
800
1000
1500
2000
3000 4 pcs
4 pcs
5 pcs
8 pcs
10 pcs
15 pcs
Conveyor system XM
Twist degree (left
or right)
Cutting length
(mm) Number of clips
required
± 15°
± 20°
± 30°
± 45°
± 60°
± 90 800
1000
1200
1800
2400
3600 4 pcs
4 ocs
5 pcs
8 pcs
10 pcs
15 pcs
Twist degree (left
or right)
Cutting length
(mm) Number of clips
required
± 15°
± 20°
± 30°
± 45°
± 60°
± 90 900
1100
1400
2100
2800
4200 5 pcs
5 ocs
7 pcs
12 pcs
15 pcs
20 pcs
Conveyor system XH
Conveyor system X85
Twist degree (left
or right)
Cutting length
(mm) Number of clips
required
± 15°
± 20°
± 30°
± 45°
± 60°
± 90 1050
1150
1700
2500
3350
5000 5 pcs
6 ocs
9 pcs
13 pcs
17 pcs
25 pcs
