64 Assembly
XK pallet system (continued)
11 Mount the outer drip catcher in the bend. Mount set
screws as guide pins.
12 Check that the slot in the special guide rail section for
locating station is properly positioned compared to
the rulers on the locating station.
Use set screws as guide pins to connect two guide rail
sections.
