USING HARD DISK WITH PCMCIA INTERFACE
To Connect The PCMCIA Hard Disk To Your Computer
♦ Windows 95/98/Me/2000, and WindowsXP:
1. Boot into the Windows system.
2. Insert the plug of the PCMCIA interface cable into the Interface Connector of drive.
3. Make sure the Power Source Switch is at the correct position:
PC: get power from the PCMCIA socket of computer.
DC: get power from the external power.
4. If you are using the external power, connect the external power to the External Power Jack at the
rear panel of the drive. And then attach the external power to the outlet.
5. Slowly insert the PC Card of interface cable into the PCMCIA socket of computer and press firmly
until the connector is seated. Your external hard disk is now ready for use in few seconds.
♦ Windows NT, and DOS/Windows 3.1:
1. Power-off the computer.
2. Insert the plug of the PCMCIA interface cable into the Interface Connector of drive.
3. Make sure the Power Source Switch is at the correct position:
PC: get power from the PCMCIA socket of computer.
DC: get power from the external power.
4. If you are using the external power, connect the external power to the External Power Jack at the
rear panel of the drive. And then attach the external power to the outlet.
5. Slowly insert the PC Card of interface cable into the PCMCIA socket of computer and press firmly
until the connector is seated.
6. Power-on computer, the external hard disk will ready for use after boot into the operating system.
