Rev. 2/00 -3.1- 300/301
The enclosure should be mounted in an area that is
convenient for servicing, calibration or for observation
of the LCD readout.
1. Locate the transmitter within the length of
transducer cable that was supplied with the
D300/301 system. If this is not possible, do not
attempt to add additional cable to the transducer.
Contact the Dynasonics factory to coordinate an
exchange for the proper cable length. Transducer
cables that are up to 300 feet [90 meters] are
available.
2. Mount the D300/301 transmitter in a location that
is:
♦
Where little vibration exist.
♦
Protected from falling corrosive fluids.
♦
Within ambient temperature limits - 22 to 122°F
[30 to 50°C]
♦
Out of direct sunlight. Direct sunlight may
increase temperatures within the transmitter to
above maximum limit.
3. Mounting: Refer to Figure 3.1 for enclosure and
mounting dimension details. Ensure that enough
room is available to allow for door swing,
maintenance and conduit entrances. Secure the
enclosure to a flat surface with four appropriate
fasteners.
4. Conduit holes. Conduit hubs should be used
where cables enter the enclosure. Holes not used
for cable entry should be sealed with plugs.
NOTE: Use NEMA 4 [ IP65 ] rated fittings plugs to
maintain the water tight integrity of the enclosure.
Generally, the left conduit hole (viewed from front) is
PART 3 - TRANSMITTER INSTALLATION
Installation of
Transmitter Box
