Aiphone KB Series

13710 (28 13 00) - 9

1.

Mounting: [Flush mount in standard 2-gang box] [Surface mount by adding Model SBX-
2G].

Specifier Notes: Specify faceplate material.

2.

Faceplate: [Stainless steel] [Brass, add ICP-BR panel] [Antique brass, add Model ICP-
AB panel].

3. Weather

resistant.

I.

Audio Door Station: Model IE-SS.

Specifier Notes: Specify flush or surface mount.

1.

Mounting: [Flush mount in standard 2-gang box] [Surface mount by adding Model SBX-
2G].

2.

Faceplate: Stainless steel.

3. Vandal

resistant.

4. Weather

resistant.

J.

Audio Door Station: Model IE-SSR.

Specifier Notes: Specify flush or surface mount.

1.

Mounting: [Flush mount in standard 2-gang box] [Surface mount by adding Model SBX-
2G].

2.

Faceplate: Stainless steel.

3.

Call Button: Red mushroom.

4. Vandal

resistant.

5. Weather

resistant.

K.

Accessory Station: Model HID-SS.
1.

Card Reader: Embedded “HID ProxPoint Plus”.

Specifier Notes: Specify flush or surface mount. When surface mounting Models IE-SS or IE-SSR with
Model HID-SS, specify Model SBX-2BH for horizontal mounting or Model SBX-2BV for vertical
mounting.

2.

Mounting: [Flush mount in standard 2-gang box] [Surface mount by adding Model SBX-
2G].

3. Vandal

resistant.

4. Weather

resistant.


2.3 ACCESSORIES

Specifier Notes: Aiphone Corporation has tested and approved the following cables for the KB Series
color-tilt video entry system. Since the KB Series transmits its audio and video signals digitally, it is
imperative the proper cable is used.
