A. Cables: Install color-tilt video entry system with the following cables, without exception:
1. Aiphone
“871802”.
2. West Penn “D990”.
Specifier Notes: Specify required accessories. Delete accessories not required. Consult Aiphone
Corporation for more information.
B. Call Extension Speaker: Model IER-2.
Specifier Notes: When using electric door strikes not manufactured by Aiphone Corporation, specify
door release adaptor Model RY-3DL or Form C door release relay Model RY-24L.
C. Electric Door Release: Model EL-9S or door strike suitable for door being released.
1.
12 V AC, 350 mA.
D. Form C Door Release Relay: Model RY-24L.
1. 1
door.
E. Selective Door Release Relay: Model RY-3DL.
1.
Mounting: Single-gang surface mount.
2. Maximum of 3 doors.
F. Picture Memory Unit: Model KC-32EU.
1.
Memory: Maximum 60 images.
2. Power Source: 24 V DC.
G. Auxiliary Light Control Relay: Model MAW-B.
1.
External light turns on when Model KB-DAR call button or inside monitor button is
pressed.
2. Power Source: 24 V DC.
H. 30-Degree Angle Box for Model KB-DAR: Model KAW-D.
1.
Mounting: Single-gang surface mount.
I. Stainless Steel Panel for Model KB-DAR: Model KA-DGR PANEL.
1.
Mounting: Single-gang surface mount.
J. Stainless Steel Flush Mount Kit for Model KB-DAR: Model KA-FSH.
1.
Mounting: Flush mount with backbox.
2. Faceplate: Stainless steel.
3. [Weather protection hood.]
K. Video Modulator Adaptor: Model KBW-M.
1.
Converts signal of standard CCTV camera to 2-wire signal, compatible with color-tilt video
entry system.
2. Allows use of color camera on video input on color-tilt video entry system, viewable from
any monitor in system.
PART 3
EXECUTION
