6. Communication:
a. Simultaneous with handset.
b. Handset by initiating caller with hands-free reply from room station internally called.
7. Power switch.
8. Handset.
9. Microphone.
10. Speaker.
11. Video
Monitor:
a. 4-inch direct-view TFT color LCD.
b. Scanning Lines: 525.
12. ALL CALL button.
13. MONITOR Button: Instantly turns on audio and video of door station, to monitor hands
free, or to extend while communicating.
14. Station selector button.
15. Door release button.
16. Tilt Control Button: Move door camera vertically from 0 degrees to approximately 40
degrees.
17. Door call-in LED 1, 2, 3.
18. Screen brightness control.
19. Monitor Control: Adjust audio monitor volume of door station.
20. TONE Control Button: Adjusts chime tone and receive volumes.
21. Housing: ABS plastic.
22. Color: White.
23. Operating Temperature: 32 degrees F to 104 degrees F (0 degrees C to 40 degrees C).
Specifier Notes: Specify required sub master station models. Delete sub master station models not
required.
C. Sub Master Station with Monitor: Model KB-3HRD.
1.
Description: Audio-video sub room station.
2. Supports: Maximum of 4 units per system, daisy chained from Model KB-3MRD.
3. Power: 24 V DC.
4. Current Consumption:
a. Maximum: 410 mA.
b. Standby: 80 mA.
5. Call-in from Door Stations:
a.
Door Station 1: 4-stroke chime.
b. Door Station 2: 2-stroke chime.
c. Door Station 3: Fast 8-stroke chime.
d. Pre-tone and voice for internal call, with adjustable volume.
6. Communication:
a. Simultaneous with handset.
b. Hands-free simultaneous at room station internally called.
7. Power switch.
8. Handset.
9. Microphone.
10. Speaker.
11. Video
Monitor:
a. 4-inch direct-view TFT color LCD.
b. Scanning Lines: 525.
12. ALL CALL button.
