Brush/pad application guide (suggestions only)
Models
MIDLITE GRIT 180
MIDGRIT 240
PROLENE
PROLITE
UNION MIX
General cleaning:
Concrete
Terrazzo fl oor
Ceramic tiles/quarrystones
Marble
Vinyl tiles
Rubber tiles
Polishing:
Rubber tiles
Marble
Vinyl tiles
Squeegee installation
Install the squeegee (21) and fasten it with the handwheels (22), then connect the vacuum hose (11) to the squeegee.
1.
With the handwheel (23), adjust the squeegee so that the rear blade - in all its length - touches the fl oor and the front blade is
2.
slightly detached from the fl oor.
Solution tank fi lling
Use the rear fi ller neck (32) or the front fi ller neck (34) to fi ll the tank (16) with a solution suitable for the work to be performed.
1.
Do not fi ll the solution tank completely, leave a few centimetres from the edge. Use the removable hose (13) as reference.
Always follow the dilution instructions on the label of the chemical product used to prepare the solution.
The solution temperature must not exceed 40°C.
CAUTION!
Use only low-foam and non-fl ammable detergents, intended for automatic scrubber applications.
MACHINE START AND STOP
Starting the machine
Prepare the machine as shown in the previous paragraph.
1.
Drive the machine to the working place by pushing it with the hands on the handlebar (2).
2.
Connect the power supply cable (3) to the electrical mains.
3.
WARNING!
Before connecting the power supply cable to the electrical mains, check that frequency and voltage, shown on
the machine serial number plate, match the electrical mains voltage.
Lower the squeegee (21) with the lever (7).
4.
Lower the brush/pad-holder deck by pressing the pedal (8).
5.
Press the brush/pad-holder switch (51) and the vacuum system switch (52).
6.
Press the solution fl ow control switches (54) as necessary, depending on the type of cleaning to be performed.
7.
To turn on the brush/pad-holder press one of the switches (55).
8.
Start cleaning, by moving the machines with the handlebar (2).
9.
Stopping the machine
Stop the machine with the handlebar (2).
10.
Stop the brush/pad-holder by releasing the switches (55).
11.
Turn off the brush/pad-holder and the vacuum system by pressing the switches (51) and (52).
12.
Disconnect the power supply cable (3) from the electrical mains and place it on the holder (4).
13.
Lift the brush/pad-holder deck by pressing the pedal (8).
14.
Lift the squeegee (21) with the lever (7).
15.
Make sure that the machine cannot move independently.
