10 SCRUBTEC 653E 9097060000(2)2009-10 A
ENGLISH USER MANUAL
USE
WARNING!
On some points of the machine there are some adhesive plates indicating:
DANGER –
WARNING –
CAUTION –
CONSULTATION –
While reading this Manual, the operator must pay particular attention to the symbols shown on the plates.
Do not cover these plates for any reason and immediately replace them if damaged.
BEFORE MACHINE START-UP
Brush/pad-holder installation/removal
Place the brush (A, Fig. 1) or the pad-holder (B) under the deck (14). 1.
Lower the deck on the brush/pad-holder by pressing the pedal (8). 2.
Connect the power supply cable (3) to the electrical mains. 3.
Engage the brush or pad-holder by pressing the switch (51) for a few seconds. 4.
Press one of the switches (55) to engage the brush or the pad-holder. 5.
WARNING!
Do not press the switches (55) too much, otherwise the machine will start.
To remove the brush/pad-holder lift the deck by pressing the pedal (8), then manually remove the brush/pad-holder from the 6.
hub, by turning it in the opposite direction to the normal rotation direction.
S311334
Figure 1
Types of brushes available
530 mm-models
PROLENE
MIDLITE GRIT 180
MIDGRIT 240
PROLITE
UNION MIX
