MACHINE DESCRIPTION
MACHINE STRUCTURE
15 10 25 22 11 21 23 22 30
8b
8a
37
39
38
20
24
25
8
32
7
3
4
12
5
9
13
14
16
17
18
19
1
2
6
28
34
35
26 27
29 36
31
33
P100122
Control panel
2.
Handlebar
3.
Power supply cable
4.
Power supply cable holder
5.
Recovery water drain hose plug
6.
Brush/pad-holder switches
7.
Squeegee lifting/lowering lever
8.
Deck lifting/lowering pedal
9.
Pedal position when deck is lifted
8a.
Pedal position when deck is lowered
8b.
Rear steering wheel
10.
Front wheels on fi xed axle
11.
Squeegee vacuum hose
12.
Recovery water drain hose
13.
Solution drain and level check hose
14.
Brush/pad-holder deck
15.
Brush/pad-holder
16.
Solution tank
17.
Recovery tank
18.
Recovery tank cover
19.
Can holder
20.
Solenoid valve
21.
Squeegee
22.
Squeegee mounting handwheels
23.
Squeegee balance adjusting handwheel
24.
Solution fi lter
25.
Solution tap
26.
Recovery water tank cover (opened to be cleaned)
26a.
Recovery water tank cover (opened)
26b.
Tank cover gasket
27.
Cover movable retaining plate
28.
Cover fi xed retaining plate
29.
Squeegee bumper wheel
30.
Serial number plate/technical data/conformity certifi cation
31.
Solution rear fi ller neck
32.
Vacuum grid with automatic shut-off fl oat
33.
Solution front fi ller neck
34.
Filter
35.
Recovery water tank retaining plate (do not remove!)
36.
Machine straight forward movement adjusting handwheel
37.
Machine forward speed adjusting handwheel
38.
Brush bumper wheels
39.
