Nilfisk-ALTO SCRUBTEC 653E - Manual (Page 46)

8 SCRUBTEC 653E 9097060000(2)2009-10 A
ENGLISH USER MANUAL
TECHNICAL DATA
Item Value
Power supply 230 V, 50-60 Hz
Machine height 1,088 mm
Solution tank capacity 55 litres
Recovery tank capacity 55 litres
Front wheel diameter 250 mm
Front and rear wheel specifi c pressure on the fl oor 1.0 N/mm 2 - 1.2 N/mm 2
Rear wheel diameter 100 mm
Vacuum system motor power 550 W, 50-60 Hz
Gradeability 2%
Sound pressure level at workstation (ISO 11201, ISO 4871) (LpA) 67.3 dB(A) ± 3 dB(A)
Machine sound pressure level (ISO 3744, ISO 4871) (LwA) 84 dB(A)
Vibration level at the operator’s arms (ISO 5349-1) < 2.5 m/s 2
Vacuum system circuit capacity 1,316 mm H
2
O
Cleaning width 530 mm
Squeegee width 760 mm
Machine maximum length 1,306 mm
Machine width without squeegee 541 mm
Brush diameter 530 mm
Weight with empty tanks 138 kg
Maximum weight with full tanks 195 kg
Brush motor power 1,100 W, 50-60 Hz
Brush speed 150 rpm
Brush pressure 30 kg
