2.3.1 Loading for Presenter Mode

The printer must be configured for use in “Presenter Mode”. See section 3.5 for connecting and
configuring the printer’s settings.
1) Load media as described in Section 2.3, (steps 1-3).
2) Remove about 8 inches (200mm) of labels from the Media Backing.
3) Open the Peeler Door. Route the media as shown below.
312
 Media Backing
 Peeler Door
4) Pull the media backing tight and then close the Peeler Door.
5) Press the
button a couple of times to normalize tracking. The printer should advance the media to
the start of the next label for each press.
 With some types of media it may be necessary to periodically remove slack in the backing (liner)
material that accumulates before the Peeler Door. To remove: Hold the Peeler Door closed and pull
on the backing material until the slack is removed and is tight.
When using the printer in presenter mode a large amount of backing can accumulate. Be sure to
contain the backing as it can become a tripping hazard. When removing backing material from the
printer do not pull the backing disturb the printer. Cut using scissors or tear using 2 hands a few
feet from the printer.
