2
Contents
The contents of the kit differ according to the type of RFID option:

HF Option*:
1 Antenna
2 Regulator CCA
3 Mounting Plate
4 Power Cable
5 Comm Cable
6 Screw (3), M4 HD 8
7 Double-Sided Tape
8 Screw, M4 HD 25
9 Short Spacer (2), .34 X .31
10 Long Spacer, .25 X .62
11 Washer
12 RF Shield
13 FCC Label
14 HF Module
3
2
4
5
1
13
8
11
10 9
7 6
12
14

UHF Option*:
1 Antenna
2 Regulator CCA
3 Mounting Plate
4 Power Cable
5 Communications Cable
6 Screw (3), M4 x 8
7 Double-Sided Tape
8 Screw (4), M3 x 6
9 I/O Cable
10 UHF Module
11 Standoff (4) M3x13
3
1
2
4
5
6 7
8
10
9
11
*Also included, but not shown, is the RFID Quick Start Guide (P/N 92-2450-01).
