Datamax-O'Neil H-Class Powered Internal Rewind Option User Manual
Page 4
2
Door
Catch
Tear Plate
Thumbscrew
Access
Cover
B) Press down on the Catch, then pull
forward to remove the Door.
C) Raise the Access Cover and remove
your media from the printer. Then,
remove the Thumbscrew and Tear
Plate. (Alternately, if equipped with a
Cutter or Present Sensor, remove that
device.)
D) Remove the Cover Screw and the
Cover Plate.
Cover Plate
Cover Screw
