MAGNETIC INCREMENTAL ENCODERS, HHM3 RANGE
OUTPUT ELECTRONIC / POWER SUPPLY
2G2 electronic (100kHz)
Supply : 5Vdc 10%
Cons. without load : 40mA max
Current per channel : 40mA max
0 max (Is=20mA) : V
ol
= 0,5Vdc
1 min (Is=20mA) : V
oh
= 2,5Vdc
PG5
2G2
PG5 electronic(100kHz)
Supply : 5 to 30Vdc
Cons. without load : 40mA max
Current per channel : 40mA max
0 max (Is=20mA) : V
ol
= 0,5Vdc
1min (Is=20mA) : V
oh
= Vcc-3Vdc
Protection against short circuits and inversion of polarity for the electronic PG5
STANDARD CONNECTION
-
+
A
B
0
A/
B/
0/
Ground
G3
PVC cable,
8 wires
WH
white
BN
brown
GN
green
YE
yellow
GY
grey
PK
pink
BU
blue
RD
red
Main
shield
GM M12 connector
8 pinouts
1
2
3
4
5
6
7
8
Connector
body
ORDERING REFERENCE
(Contact the factory for special versions , ex : stainless steel version, connections…)
Shaft
Supply
Output stage
Signals
Resolution
Connection
Connection
orientation
GM : M12
8 pinouts
A : axial
HHM3
06 :
6mm
2G2 : 5Vdc
TTL / RS422 output
PG5 : 5 to 30Vdc
Push-pull output
(TTL / RS422 available if
encoder supply is 5Vdc)
9 :
A, A/,
B, B/,
0, 0/
1024
max
G3 : PVC
cable 8
wires
D020 : diagonal
cable 2m
Ex: HHM3_
06 //
PG5
9 //
01024 //
G3
A020
Available resolutions
: 32 64 128 256 1024
Made in FRANCE
Changes possible without further notice V2.0
