8
LC Base Model Description
-
LC
-
038 3
-
0
-
A A 0 A
-
0 0 0
Series and
Generation
Unit Size Voltage Blank A1 A2 A3 A4 B1 B2 B3
BASE MODEL
LC
SERIES AND GENERATION
005 = 5 Nominal Tons
UNIT SIZE
006 = 6 Nominal Tons
007 = 7 Nominal Tons
008 = 8 Nominal Tons
012 = 12 Nominal Tons
015 = 15 Nominal Tons
019 = 19 Nominal Tons
021 = 21 Nominal Tons
026 = 26 Nominal Tons
027 = 27 Nominal Tons
029 = 29 Nominal Tons
038 = 38 Nominal Tons
047 = 47 Nominal Tons
054 = 54 Nominal Tons
1 = 230V/1Φ/60Hz
VOLTAGE
2 = 230V/3Φ/60Hz
3 = 460V/3Φ/60Hz
4 = 575V/3Φ/60Hz
8 = 208V/3Φ/60Hz
9 = 208V/1Φ/60Hz
0 = Standard
BLANK
FEATURE A: COOLING
A = R-410A Variable Capacity Scroll Compressors
A1: COOLING STYLE
0 = Air-Cooled Condenser, Low Water Flow
A2: COOLING CONFIGURATION
A = Air-Cooled Condenser, High Water Flow
0 = Standard
A3: COOLING COATING
1 = Polymer E-Coated Condenser Coil
A = Shell and Tube Heat Exchanger
A4: COOLING STAGING
B = Brazed Plate Heat Exchanger
C = Oversized Shell and Tube Heat Exchanger
D = Oversized Brazed Plate Heat Exchanger
FEATURE B: BLANK
0 = Standard
B1: BLANK
0 = Standard
B2: BLANK
0 = Standard
B3: BLANK
Model Number
