Installation Instructions TS218SU
5
TOOLS REQUIRED FOR INSTALLATION
PARTS
1/8" - wood studs #2 7/16" (11.1mm)
8mm - concrete
concrete only
J (1)
[faceplate]
[top cover]
[bottom cover]
E2 (8)
1/4"
"A"
"B"
"C"
"D"
"E"
A1 (4)
M4x12mm
A2 (4)
M4x16mm
A3 (4)
M4x25mm
B1 (4)
M5x12mm
B2 (4)
M5x16mm
B3 (4)
M5x25mm
C1 (4)
M6x12mm
C2 (4)
M6x16mm
C3 (4)
M6x25mm
D1 (4)
M8x12mm
D2 (4)
M8x20mm
D3 (4)
M8x30mm
E1 (4)
[universal washer]
E3 (4)
D4 (1)
M5
M8
H (1)
[main assembly]
K (1)
L (1)
F (3)
1/4 x 2 1/2"
G (3)
[concrete anchor]
M (2)
[roll flange spacer] N (2)
#10-24
P (2)
[top right bracket]
Q (2)
[top left bracket]
R (8)
1/4-20 x 3/8"
S (1)
5/32"
T (1)
3/16" U (1)
1/8"
