CASTLE, INC TSM-35 OWNERS MANUAL V1.2 Page 29 of 33
7 Service and Maintenance
Warning: Electrical hazard: Do not attempt to service Control Box components. Contact Castle,
Inc. for the proper service information.
7.1 General
To ensure productivity and longevity for your Castle Screw Pocket Machine, it is essential to
follow a few simple steps. How often these steps are performed depends upon the number of
hours the machine is operated each day. As a general rule, operators should visually inspect
the machine at the start of each work shift in the following manner:

Check oil level in the drill lubricator.

Check power cord and Foot Switch cord for wear or damage.

Check spindle bearings for rough or noisy operation

Ensure that the router bit and the drill bit are clean, sharp and undamaged.

Check belt for wear or damage.

Keep the router and drill motors free from dust build up.

Check for proper Safety Switch function. Turn the machine on and press the Foot
Switch without a work piece against the Safety Buttons. If the Safety Switch is working
properly the machine should not cycle. If you suspect a Safety Switch malfunction,
contact Castle, Inc. at 800.282.8338 as soon as possible for corrective action.

It is recommended that periodically (at least once per 40 hours of operation) you blow
out all upper areas of your model TSM-35 by turning off the power supply and lifting the
Case Top to its fully open position. Blow out the compartment with approximately 30 PSI
compressed air. Pay particular attention to keeping the Interlock Safety Switch free of
sawdust.
Caution: Always wear safety goggles when using compressed air.
